RHEALP035-RL
By:
Additional information
CNY¥24.60
The prices shown are for retail purchases only. For bulk orders, project requirements, or wholesale pricing, please contact us with your quantity details to receive a tailored quotation
Ready for delivery in 4–5 weeks
Illuminate with Precision: Profile Light – RHEALP035-RL
The RHEALP035-RL profile light emerges as a sleek, high-performance linear lighting solution engineered for both functional and aesthetic excellence. Designed for architects, interior designers, lighting consultants, and contractors seeking refined linear illumination, this profile delivers tailored lighting with minimal visual clutter.
At just 8.4 mm height (0.33″) from the architectural surface, the RHEALP035-RL integrates seamlessly into ceilings, walls, furniture or cove elements, creating crisp, uninterrupted light lines. A durable aluminium extrusion serves both as structural support and passive heatsink, promoting superior thermal management and extending LED longevity. Coupled with a PMMA diffuser, it ensures a dot-free, uniform beam free of hotspots or visible LED points.
Installation is simple yet flexible: the channel accepts standard LED strips up to 10 mm width, allows through-wiring or side/bottom cable exits, and includes optional end caps (with or without holes) for clean terminations. The design supports continuous runs with near‐invisible joints, ideal for long corridors, ceiling coves, wall niches, feature walls, wardrobes or display cases.
This profile is available in standard lengths (1 m, 2 m, 3 m) or customization to suit project demands. Depending on the environment, select IP ratings can be applied to protect against dust or moisture making it suitable even in semi-protected wet zones. Finishes like white, silver or black powder coatings allow it to blend into design schemes or serve as subtle accent elements.
For lighting professionals, RHEALP035-RL underpins efficient, glare-controlled layouts. Use it for ambient washes, accent lines, under-cabinet illumination, ceiling slot lighting, or integrated furniture lighting. The diffused light output, combined with properly selected LED strips (high CRI, tunable CCT, dimmable drivers), delivers premium experiential lighting for residential, retail, hospitality or commercial interiors.
With its minimalist profile, thermal efficiency, and modular flexibility, the RHEALP035-RL becomes the backbone for refined architectural lighting satisfying both the technical rigour demanded by designers and the aesthetic sensibilities of home-conscious users.
Key Benefits at a Glance:
- Ultra low-profile (8.4 mm height) for seamless integration
- Uniform PMMA diffusion for glare-free, dot-free light lines
- Aluminium housing functions as heatsink for long LED life
- Support for continuous runs and clean end terminations
- Compatible with 10 mm LED strip widths
- Custom lengths, finishes, and IP options
- Ideal for coves, niches, wardrobes, ceilings, walls
| Material: | AL6063-T5 |
| IP Rating: | IP20 |
| PC Cover: | Diffused/Black |
| Accessories: | 15º Frosted Lens |
| Size: | 1000*10*16mm (L*W*H) |
| Maximum Length: | 3000mm |
| Finish: | Anodized/White/Black |
The price is quoted on an Ex-Works (China) basis. Please hold off on making any payment at this time. A pro forma invoice covering the fixtures, shipping, and bank charges will be issued within one to two business days. Please note that customs duty is not included in the pro forma invoice
Kindly specify the items and quantities you’re interested in, along with your complete shipping address, and we will promptly provide you with a detailed quote.
